12 / 24 / 48Vdc 500W Battery Charger / Precision Power Supply – NSR Series

  • Dual-function design: precision DC power supply and intelligent battery charger
  • Available with 12Vdc, 24Vdc, or 48Vdc nominal output
  • Programmable charging with temperature compensation for extended battery life
  • Deep discharge protection, LVD, and electronic circuit breaker (ECB)
  • Standard RS-485 MODBUS RTU; optional Ethernet/SNMP for remote monitoring
  • M8 terminals standard; Phoenix connectors available on 24Vdc / 48Vdc models
More Information...
SKU: NSR500F
Brand: Helios Power Solutions
NSR Series units are assembled to order, to meet your specifications. Please allow 1-2 weeks for assembly and dispatch.

From: AUD $1,377.00(From: AUD $1,514.70 inc GST)

Note: Australian GST only applies to orders delivered within Australia. International orders are exclusive of GST.

Volume discounts are automatically applied when added to the cart.
QuantityDiscountPer Unit Price
1-4 0% AUD $1,377.00
5-9 3% AUD $1,335.69
10+ 5% AUD $1,308.15
Volume discounts are automatically applied when added to the cart.
QuantityDiscountPer Unit Price
1-4 0% AUD $1,662.00
5-9 3% AUD $1,612.14
10+ 5% AUD $1,578.90
Volume discounts are automatically applied when added to the cart.
QuantityDiscountPer Unit Price
1-4 0% AUD $1,377.00
5-9 3% AUD $1,335.69
10+ 5% AUD $1,308.15
Volume discounts are automatically applied when added to the cart.
QuantityDiscountPer Unit Price
1-4 0% AUD $1,662.00
5-9 3% AUD $1,612.14
10+ 5% AUD $1,578.90
Volume discounts are automatically applied when added to the cart.
QuantityDiscountPer Unit Price
1-4 0% AUD $1,377.00
5-9 3% AUD $1,335.69
10+ 5% AUD $1,308.15
Volume discounts are automatically applied when added to the cart.
QuantityDiscountPer Unit Price
1-4 0% AUD $1,662.00
5-9 3% AUD $1,612.14
10+ 5% AUD $1,578.90
Volume discounts are automatically applied when added to the cart.
QuantityDiscountPer Unit Price
1-4 0% AUD $1,377.00
5-9 3% AUD $1,335.69
10+ 5% AUD $1,308.15
Volume discounts are automatically applied when added to the cart.
QuantityDiscountPer Unit Price
1-4 0% AUD $1,662.00
5-9 3% AUD $1,612.14
10+ 5% AUD $1,578.90
Volume discounts are automatically applied when added to the cart.
QuantityDiscountPer Unit Price
1-4 0% AUD $1,377.00
5-9 3% AUD $1,335.69
10+ 5% AUD $1,308.15
Volume discounts are automatically applied when added to the cart.
QuantityDiscountPer Unit Price
1-4 0% AUD $1,662.00
5-9 3% AUD $1,612.14
10+ 5% AUD $1,578.90

Description

NSR500F – 500W Battery Charger / Precision DC Power Supply (12, 24, or 48Vdc)

The Helios NSR500F is a compact, high-efficiency 500W battery charger and precision DC power supply available in 12Vdc, 24Vdc, or 48Vdc models. Designed for fixed industrial and infrastructure applications, it provides stable, regulated DC output while delivering advanced charging capabilities. Typical uses include telecommunications, laboratories, industrial process control, SCADA networks, and rail signalling systems.

As part of the NSR Series, the NSR500F combines rugged design with precision regulation and intelligent battery management. Features include programmable charging algorithms, low-voltage disconnect (LVD), electronic circuit breaker (ECB) protection, and deep discharge protection—ensuring battery longevity and reliable system performance.

The NSR500F supports a wide range of battery chemistries, including sealed lead-acid (SLA), AGM, Gel, and Lithium-ion. Its 90–264Vac input range, high conversion efficiency (up to 90%), and IP20-rated chassis make it well suited to critical environments where reliability is essential.

All models are equipped with RS-485 MODBUS RTU for monitoring and control, while optional Ethernet/SNMP adds web-based configuration, data logging, and remote diagnostics. Local LED indicators and programmable alarm relays provide additional status and fault information, ensuring integration with SCADA, PLC, and remote telemetry systems.

The NSR500F is offered with M8 stud terminals as standard, with Phoenix connectors available on 24Vdc and 48Vdc models. Its combination of precision regulation, flexibility, and robust construction makes it one of the most versatile DC charger and power supply solutions available.

The NSR Series is engineered and built in Australia, delivering trusted performance for critical DC power systems worldwide.

Primary Features and Benefits

  • Dual-function design: precision DC power supply and intelligent battery charger
  • Available with 12Vdc, 24Vdc, or 48Vdc nominal output
  • Programmable charging with temperature compensation for extended battery life
  • Deep discharge protection, LVD, and electronic circuit breaker (ECB)
  • Standard RS-485 MODBUS RTU; optional Ethernet/SNMP for remote monitoring
  • M8 terminals standard; Phoenix connectors available on 24Vdc / 48Vdc models

Key Applications

  • Telecommunications and networking systems
  • Laboratory and precision industrial equipment
  • SCADA, automation, and process control
  • Rail signalling and transport infrastructure
  • Utility substations and energy storage systems

Safety Features

  • Input fuse protection, varistor, and surge suppression
  • Electronic circuit breaker (ECB) for battery circuit protection
  • Overcurrent, short circuit, and overvoltage protection
  • Ingress protection: IP20 rated enclosure
  • Isolation ratings (I/P–O/P, I/P–FG, O/P–FG) meet industrial safety standards

Additional information

Weight4 kg
Dimensions304 × 225 × 70 mm
Output Power (Range)

Input Voltage

,

Output Voltage (Nominal)

, ,

Output Terminals

M8 Studs, Phoenix Terminals

Communications

,

Specifications

Specification Summary – NSR500F

ParameterSpecification
Power Rating500W
Nominal Output Voltages12Vdc, 24Vdc, or 48Vdc (configurable by model)
Output Current12Vdc: ~41A
24Vdc: ~20.8A
48Vdc: ~10.4A
Input Voltage Range90–264Vac
EfficiencyUp to 90%
Operating ModesBattery charger mode / Precision DC power supply mode
Battery CompatibilitySLA, AGM, Gel, Lithium-ion
Protection FeaturesECB, LVD, deep discharge, surge suppression, overcurrent, short circuit, overvoltage
Operating Temperature–10°C to +50°C
CoolingDual-fan cooling
CommunicationsRS-485 MODBUS RTU standard; optional Ethernet/SNMP
Indicators & AlarmsLEDs, alarm relays, fault signalling
TerminalsM8 studs (all models)
Phoenix connectors (24Vdc / 48Vdc models only)
Ingress ProtectionIP20
IsolationI/P–O/P: 3kVac
I/P–FG: 2kVac
O/P–FG: 500Vac
Dimensions (L × W × H)277 × 156 × 69 mm
Weight2.5 kg

This specification summary may contain errors. Please refer to the product datasheet for full specifications.

Range Summary

NSR500F Series Range Summary

SKUNominal VoltageOutput CurrentPower RatingTerminalsCommunications
NSR500F12S12Vdc~41A500WM8 studsRS-485 MODBUS RTU
NSR500F12SC12Vdc~41A500WM8 studsRS-485 MODBUS RTU + Ethernet/SNMP
NSR500F24S24Vdc~20.8A500WM8 studsRS-485 MODBUS RTU
NSR500F24SC24Vdc~20.8A500WM8 studsRS-485 MODBUS RTU + Ethernet/SNMP
NSR500F24T24Vdc~20.8A500WPhoenix connectorsRS-485 MODBUS RTU
NSR500F24TC24Vdc~20.8A500WPhoenix connectorsRS-485 MODBUS RTU + Ethernet/SNMP
NSR500F48S48Vdc~10.4A500WM8 studsRS-485 MODBUS RTU
NSR500F48SC48Vdc~10.4A500WM8 studsRS-485 MODBUS RTU + Ethernet/SNMP
NSR500F48T48Vdc~10.4A500WPhoenix connectorsRS-485 MODBUS RTU
NSR500F48TC48Vdc~10.4A500WPhoenix connectorsRS-485 MODBUS RTU + Ethernet/SNMP

This summary table may contain errors. Please refer to the product datasheet for full specifications.
