Description
ICT1500-24PM – Hot-Swappable DC Power Module – 24Vdc, 1500W
The ICT1500-24PM is a high-capacity 24Vdc rectifier module providing up to 1500W continuous power for demanding DC networks. Factory-set to 27.6Vdc with a wide adjustment range, it is ideal for powering radio, broadband and industrial equipment at centralised or remote network nodes.
Its hot-swappable design allows modules to be added, removed or replaced under load without downtime. Multiple modules can be used in a shelf to support N+1 redundancy or scalable full-load operation, ensuring maximum system uptime for mission-critical infrastructure.
When integrated into ICT intelligent power systems, the ICT1500-24PM provides comprehensive remote management including voltage adjustment, alarm reporting, SNMP, data logging and environmental monitoring.
Features and Benefits
- 1500W continuous 24Vdc output for high-demand network equipment.
- Factory-set 27.6Vdc with adjustable range of 23.0–31.0Vdc.
- Up to 92% efficiency to reduce power consumption and heat output.
- Active PFC improves AC input efficiency and reduces harmonics.
- Hot-swappable with Oring MOSFETs for safe parallel operation.
- Supports N+1 redundancy when used in ICT managed power shelves.
Key Applications
- Telecommunications 24Vdc power infrastructure
- Access and backhaul radio equipment
- SCADA, industrial automation and IoT systems
- Airports, transport and critical surveillance nodes
- Expandable network power upgrades in existing ICT systems
Safety Features
- Over-temperature and over-current shutdown for system protection.
- Input and output over-voltage protection for connected equipment.
- Built-in Oring MOSFET to prevent reverse feed between modules.
- Current limiting and fan failure detection with alarm functions.
- −30°C to +60°C operating range with de-rating above +50°C.
Safety & Compliance
- Designed to EN62368-1 safety standard (when installed in compliant shelves).
- Meets FCC Part 15/B emissions and EN55032, EN61000-6-2 / EN61000-6-3 immunity.
- RoHS compliant device construction.
Compatible ICT Power Systems
- ICT Modular Power Series – Fully managed DC systems supporting 1500W modules.
- ICT Hybrid Power Series – 1RU hybrid AC/DC power shelves with modular configuration.
- ICT MPS Ultra – High-density 2RU power systems up to 12kW.
- ICT Hybrid Ultra – Hybrid DC systems with integrated battery management.
